BCP52 - onsemi
Trans Gp Bjt PNP 60V 1.2A 1500MW 4-PIN(3+TAB) SOT-223 T/r / Trans PNP 60V 1.2A SOT-223
Technical Details
| Case/Package | SOT-223 |
| China RoHS | Compliant |
| Collector Base Voltage (VCBO) | -60V |
| Collector Emitter Breakdown Voltage | 60V |
| Collector Emitter Saturation Voltage | 500mV |
| Collector Emitter Voltage (VCEO) | 60V |
| Contact Plating | Tin |
| Country of Origin | Philippines |
| Current Rating | -1.2A |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Emitter Base Voltage (VEBO) | -5V |
| Height | 1.6mm |
| hFE Min | 25 |
| Introduction Date | 1994-01-01 |
| Lead Free | Lead Free |
| Length | 6.5mm |
| Lifecycle Status | Obsolete |
| Manufacturer Lifecycle Status | OBSOLETE |
| Max Breakdown Voltage | 60V |
| Max Collector Current | 1.2A |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 1.5W |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Elements | 1 |
| Number of Pins | 4 |
| Number of Terminals | 4 |
| Polarity | PNP |
| Power Dissipation | 1.5W |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8541290080, 8541290080|8541290080|8541290080|8541290080|8541290080 |
| Voltage Rating (DC) | -60V |
| Weight | 188mg |
| Width | 3.5mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
Images
Component Sense
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Diodes Inc. | Production | ||
| Nexperia | Production | ||
| onsemi | Production | ||
| Panasonic | Obsolete | ||
| Central Semiconductor | Obsolete | ||
| onsemi | Obsolete | ||
| Diodes Inc. | Obsolete | ||
| Diodes Inc. | Production | ||
| STMicroelectronics | Obsolete | ||
| Diodes Inc. | Production |
