FDD4141 - onsemi
Transistor: P-MOSFET; unipolar; -40V; -50A; 12.3ohm; 69W; -55+175 deg.C; SMD; TO252(DPAK)
Technical Details
| Case/Package | TO-252 |
| China RoHS | Non-Compliant |
| Contact Plating | Tin |
| Continuous Drain Current (ID) | 50A |
| Drain to Source Breakdown Voltage | -40V |
| Drain to Source Resistance | 12.3mΩ |
| Drain to Source Voltage (Vdss) | -40V |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Fall Time | 15ns |
| Gate to Source Voltage (Vgs) | 20V |
| Height | 2.517mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.29.00.95 |
| Input Capacitance | 2.775nF |
| Introduction Date | 2007-07-24 |
| Lead Free | Lead Free |
| Length | 6.73mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Junction Temperature (Tj) | 150°C |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 69W |
| Min Breakdown Voltage | 40V |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Nominal Vgs | -1.8V |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 3 |
| Number of Terminals | 2 |
| Packaging | Cut Tape |
| Power Dissipation | 2.4W |
| Radiation Hardening | No |
| Rds On Max | 12.3mΩ |
| REACH SVHC | No |
| Resistance | 12.3MΩ |
| Rise Time | 7ns |
| RoHS | Compliant |
| Schedule B | 8541290080, 8541290080|8541290080|8541290080|8541290080|8541290080 |
| Threshold Voltage | -1.8V |
| Turn-Off Delay Time | 38ns |
| Turn-On Delay Time | 10ns |
| Weight | 260.37mg |
| Width | 6.22mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
