FOD817ASD - onsemi
Optocoupler, Transistor Output, 1 Channel, Surface Mount DIP, 4 Pins, 50 mA, 5 kV, 80 %
Technical Details
| Case/Package | SMD/SMT |
| China RoHS | Compliant |
| Collector Emitter Breakdown Voltage | 70V |
| Collector Emitter Saturation Voltage | 200mV |
| Collector Emitter Voltage (VCEO) | 70V |
| Contact Plating | Tin |
| Country of Origin | Thailand |
| Current Transfer Ratio | 80% |
| Dark Current | 100nA |
| Fall Time | 18µs |
| Forward Current | 50mA |
| Forward Voltage | 1.4V |
| Height | 3.85mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.80.00 |
| Input Current | 50mA |
| Introduction Date | 2004-04-28 |
| Isolation Voltage | 5000Vrms |
| Lead Free | Lead Free |
| Length | 5.1mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Collector Current | 50mA |
| Max Input Current | 50mA |
| Max Junction Temperature (Tj) | 125°C |
| Max Operating Temperature | 110°C |
| Max Output Voltage | 70V |
| Max Power Dissipation | 150mW |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of Pins | 4 |
| Output Current per Channel | 50mA |
| Output Voltage | 70V |
| Packaging | Box |
| Power Dissipation | 200mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Breakdown Voltage | 6V |
| Reverse Voltage | 6V |
| Rise Time | 18µs |
| RoHS | Compliant |
| Schedule B | 8541408000, 8541408000|8541408000, 8541408000|8541408000|8541408000, 8541408000|8541408000|8541408000|8541408000 |
| Weight | 0g |
| Width | 7mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
