MAX809SN232T1G - onsemi
IC SUPERVISOR 1 CHANNEL SOT23-3 "Supervisor Push-Pull, Totem Pole 1 Channel SOT-23-3 (TO-236)"
Technical Details
| Case/Package | TSSOP |
| China RoHS | Compliant |
| Country of Origin | Malaysia |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Halogen Free | Halogen Free |
| Height | 1.01mm |
| Height - Seated (Max) | 1.11mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.60 |
| Introduction Date | 2000-02-01 |
| Lead Free | Lead Free |
| Length | 2.9mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | LIFETIME |
| Max Operating Temperature | 105°C |
| Max Reset Threshold Voltage | 2.35V |
| Max Supply Current | 2.5µA |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Reset Threshold Voltage | 2.28V |
| Min Supply Voltage | 1.2V |
| Mount | Surface Mount |
| Nominal Supply Current | 2.5µA |
| Number of Channels | 1 |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of Pins | 3 |
| Number of Terminals | 3 |
| Number of Voltages Monitored | 1 |
| Operating Supply Current | 800nA |
| Operating Supply Voltage | 3.3V |
| Overvoltage Threshold | 2.35V |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reset | Active Low |
| Reset Timeout | 140ms |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Temperature Grade | Industrial |
| Terminal Pitch | 950µm |
| Threshold Voltage | 2.32V |
| Type | Simple Reset/Power-On Reset |
| Undervoltage Threshold | 2.32V |
| Watchdog Timer | No |
| Width | 1.3mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
