Technical Details
| Case/Package | TO-247 |
| China RoHS | Non-Compliant |
| Collector Base Voltage (VCBO) | 1kV |
| Collector Emitter Saturation Voltage | 1.15V |
| Collector Emitter Voltage (VCEO) | 450V |
| Element Configuration | Single |
| Emitter Base Voltage (VEBO) | 9V |
| Gain Bandwidth Product | 13MHz |
| hFE Min | 5.5 |
| Lead Free | Contains Lead |
| Lifecycle Status | Obsolete |
| Manufacturer Lifecycle Status | OBSOLETE |
| Max Collector Current | 30A |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 180W |
| Min Operating Temperature | -65°C |
| Number of Elements | 1 |
| Number of Pins | 3 |
| Number of Terminals | 3 |
| Polarity | NPN |
| REACH SVHC | No |
| RoHS | Compliant |
| Transition Frequency | 13MHz |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
Images
Augswan
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| onsemi | Production | ||
| STMicroelectronics | Obsolete | ||
| STMicroelectronics | Obsolete | ||
| STMicroelectronics | Obsolete | ||
| STMicroelectronics | Obsolete | ||
| Toshiba | Obsolete | ||
| Sanyo | Obsolete | ||
| Fuji | Obsolete | ||
| Toshiba | Obsolete | ||
| Toshiba | Obsolete |
