MMBD353LT1G - onsemi
MMBD353LT1G Series 7 V 10 uA SMT Dual Hot Carrier Mixer Diode - SOT-23-3
Technical Details
| Capacitance | 1pF |
| Case/Package | SOT-23-3 |
| China RoHS | Compliant |
| Country of Origin | Mainland China |
| Current Rating | 80mA |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Dual |
| Forward Current | 10mA |
| Forward Voltage | 600mV |
| Halogen Free | Halogen Free |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.60 |
| Introduction Date | 1997-05-07 |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Forward Surge Current (Ifsm) | 600mA |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 225mW |
| Max Repetitive Reverse Voltage (Vrrm) | 7V |
| Min Operating Temperature | -55°C |
| Number of Elements | 2 |
| Number of Pins | 3 |
| Number of Terminals | 3 |
| Packaging | Tape and Reel |
| Peak Reverse Current | 10µA |
| Power Dissipation | 225mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Recovery Time | 5ns |
| Reverse Voltage | 7V |
| RoHS | Compliant |
| Schedule B | 8541100070, 8541100070|8541100070|8541100070|8541100070|8541100070 |
| Voltage Rating (DC) | 7V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
