MRA4007T3G - onsemi
Diode, Rectifier, Standard, Vr 1000V, If 1A, Pkg Sma, Vf 1.04V, Tj +175DEGC, Cs 30A
Technical Details
| Average Rectified Current | 1A |
| Breakdown Voltage | 1kV |
| Case/Package | SMA |
| China RoHS | Non-Compliant |
| Contact Plating | Tin |
| Current Rating | 1A |
| Element Configuration | Single |
| Forward Current | 1A |
| Forward Voltage | 1.18V |
| Height | 2mm |
| Lead Free | Lead Free |
| Length | 4.32mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Forward Surge Current (Ifsm) | 30A |
| Max Operating Temperature | 150°C |
| Max Output Current | 1A |
| Max Repetitive Reverse Voltage (Vrrm) | 1kV |
| Max Reverse Voltage (DC) | 1kV |
| Max Surge Current | 30A |
| Min Operating Temperature | -55°C |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Output Current | 1A |
| Packaging | Tape and Reel |
| Peak Non-Repetitive Surge Current | 30A |
| Peak Reverse Current | 10µA |
| Polarity | Standard |
| Radiation Hardening | No |
| REACH SVHC | No |
| Reverse Standoff Voltage | 1kV |
| Reverse Voltage | 1kV |
| RoHS | Compliant |
| Schedule B | 8541100080, 8541100080|8541100080|8541100080|8541100080|8541100080 |
| Voltage Rating (DC) | 1kV |
| Width | 2.6mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
Images
RS
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| onsemi | Obsolete | ||
| Central Semiconductor | Production | ||
| Central Semiconductor | Unknown | ||
| Rectron | Production | ||
| Diotec | Production | ||
| Central Semiconductor | Production | ||
| Diodes Inc. | Obsolete | ||
| Rectron | Production | ||
| Diodes Inc. | Production | ||
| Rectron | Production |
