NSBC123JDXV6T1G - onsemi
Small Signal Bipolar Transistor, 0.1A I(C), 50V V(BR)CEO, 2-Element, NPN, Silicon
Technical Details
| Case/Package | SOT-563-6 |
| China RoHS | Compliant |
| Collector Emitter Breakdown Voltage | 50V |
| Collector Emitter Saturation Voltage | 250mV |
| Collector Emitter Voltage (VCEO) | 50V |
| Continuous Collector Current | 100mA |
| Country of Origin | Mainland China |
| Current Rating | 100mA |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Dual |
| hFE Min | 80 |
| Introduction Date | 1999-01-01 |
| Lead Free | Lead Free |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Breakdown Voltage | 50V |
| Max Collector Current | 100mA |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 500mW |
| Min Operating Temperature | -55°C |
| Number of Elements | 2 |
| Number of Pins | 6 |
| Number of Terminals | 6 |
| Packaging | Tape and Reel |
| Polarity | NPN |
| Power Dissipation | 357mW |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Voltage Rating (DC) | 50V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
