NSIC2030JBT3G - onsemi
LED Driver, Constant Current Regulator, 120 V, 30 mA, ±15%, for A/C off-line applications
Technical Details
| Accuracy | 15% |
| Case/Package | SMB |
| China RoHS | Non-Compliant |
| Contact Plating | Tin |
| Country of Origin | Vietnam |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 2.47mm |
| Height - Seated (Max) | 2.47mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.60 |
| Introduction Date | 2014-01-23 |
| Lead Free | Lead Free |
| Length | 4.32mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Input Voltage | 120V |
| Max Input Voltage (AC) | 120V |
| Max Junction Temperature (Tj) | 175°C |
| Max Operating Temperature | 175°C |
| Max Output Current | 30mA |
| Max Power Dissipation | 3W |
| Max Supply Current | 34.5mA |
| Max Supply Voltage | 120V |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Characters | 6 |
| Number of Circuits | 1 |
| Number of Outputs | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Operating Supply Voltage | 120V |
| Output Current | 30mA |
| Packaging | Cut Tape |
| REACH SVHC | No |
| RoHS | Compliant |
| Schedule B | 8542390000, 8542390000|8542390000|8542390000|8542390000|8542390000 |
| Switching Frequency | 10MHz |
| Weight | 92.986436mg |
| Width | 3.56mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
