NTDV20P06LT4G - onsemi
Single P-Channel 60 V 150 mOhm 65 W Surface Mount Power MOSFET - TO-252-3
Technical Details
| Case/Package | DPAK |
| China RoHS | Non-Compliant |
| Continuous Drain Current (ID) | 15.5A |
| Country of Origin | Malaysia |
| Drain to Source Breakdown Voltage | -60V |
| Drain to Source Resistance | 150mΩ |
| Drain to Source Voltage (Vdss) | 60V |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Fall Time | 70ns |
| Gate to Source Voltage (Vgs) | 20V |
| Input Capacitance | 1.19nF |
| Introduction Date | 2003-07-25 |
| Lead Free | Lead Free |
| Lifecycle Status | Obsolete |
| Manufacturer Lifecycle Status | OBSOLETE |
| Max Operating Temperature | 175°C |
| Max Power Dissipation | 65W |
| Min Breakdown Voltage | 60V |
| Min Operating Temperature | -55°C |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 3 |
| Number of Terminals | 2 |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| Rds On Max | 150mΩ |
| REACH SVHC | No |
| Resistance | 150MΩ |
| Rise Time | 90ns |
| RoHS | Compliant |
| Turn-Off Delay Time | 28ns |
| Turn-On Delay Time | 11ns |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
Images
Rochester Electronics
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| onsemi | NRND | ||
| onsemi | Obsolete | ||
| onsemi | Obsolete | ||
| onsemi | Production | ||
| onsemi | Obsolete | ||
| onsemi | Obsolete | ||
| STMicroelectronics | Obsolete | ||
| Fairchild Semiconductor | Obsolete | ||
| Fairchild Semiconductor | Obsolete | ||
| onsemi | Obsolete |
Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| Rochester Electronics |
US: 33
|
$ | 0.4885 | 0.4055 | 0.3615 | |||||
