NUP412VP5T5G - onsemi
NUP412V Series 12.7 V 10 pF 0.5 uA Quad TVS Diode Array - SOT-953-5
Technical Details
| Breakdown Voltage | 12V |
| Capacitance | 10pF |
| Case/Package | SOT-953-5 |
| China RoHS | Compliant |
| Composition | Zener |
| Contact Plating | Tin |
| Country of Origin | Mainland China |
| Depth | 800µm |
| Direction | Unidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Common Anode |
| ESD Protection | Yes |
| Halogen Free | Halogen Free |
| Height | 500µm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2006-09-19 |
| Lead Free | Lead Free |
| Leakage Current | 500nA |
| Length | 1mm |
| Lifecycle Status | Obsolete |
| Manufacturer Lifecycle Status | OBSOLETE |
| Max Breakdown Voltage | 12.7V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 18W |
| Max Reverse Leakage Current | 500nA |
| Min Breakdown Voltage | 11.4V |
| Min Operating Temperature | -55°C |
| Number of Channels | 4 |
| Number of Elements | 4 |
| Number of Lines | 4 |
| Number of Pins | 5 |
| Number of Terminals | 5 |
| Number of Unidirectional Channels | 4 |
| Operating Supply Voltage | 9V |
| Packaging | Tape and Reel |
| Peak Pulse Power | 65W |
| Peak Reverse Current | 500nA |
| Polarity | Unidirectional |
| Power Line Protection | Yes |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Standoff Voltage | 9V |
| RoHS | Compliant |
| Termination | SMD/SMT |
| Test Current | 5mA |
| Width | 850µm |
| Working Voltage | 9V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
