NZQA6V8AXV5T1G - onsemi
ESD Suppressor Diode TVS Uni-Dir 4.3V 5-Pin SOT-553 T/R / TVS DIODE 4.3VWM 13VC SOT553
Technical Details
| Breakdown Voltage | 6.8V |
| Capacitance | 15pF |
| Case/Package | SOT-553-5 |
| China RoHS | Compliant |
| Clamping Voltage | 13V |
| Composition | Zener |
| Contact Plating | Tin |
| Depth | 1.3mm |
| Direction | Unidirectional |
| Element Configuration | Common Anode |
| ESD Protection | Yes |
| Halogen Free | Halogen Free |
| Height | 600µm |
| Lead Free | Lead Free |
| Leakage Current | 1µA |
| Length | 1.7mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Breakdown Voltage | 7.14V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 380mW |
| Max Reverse Leakage Current | 1µA |
| Max Surge Current | 1.6A |
| Min Breakdown Voltage | 6.47V |
| Min Operating Temperature | -55°C |
| Number of Channels | 4 |
| Number of Elements | 4 |
| Number of Lines | 4 |
| Number of Pins | 5 |
| Number of Terminals | 5 |
| Number of Unidirectional Channels | 4 |
| Packaging | Tape and Reel |
| Peak Pulse Current | 1.6A |
| Peak Pulse Power | 20W |
| Peak Reverse Current | 1µA |
| Polarity | Unidirectional |
| Power Line Protection | No |
| Power Rating | 100W |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Breakdown Voltage | 6.1V |
| Reverse Standoff Voltage | 4.3V |
| RoHS | Compliant |
| Schedule B | 8536300000, 8536300000|8536300000|8536300000|8536300000|8536300000 |
| Termination | SMD/SMT |
| Test Current | 1mA |
| Voltage Rating (DC) | 6.2V |
| Width | 1.3mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
