Technical Details
| Breakdown Voltage | 17.6V |
| Capacitance | 5pF |
| Case/Package | SOT-23 |
| China RoHS | Compliant |
| Clamping Voltage | 30V |
| Composition | Zener |
| Contact Plating | Tin |
| Depth | 1.3mm |
| Direction | Unidirectional |
| Element Configuration | Single |
| ESD Protection | Yes |
| Halogen Free | Halogen Free |
| Height | 1.01mm |
| Lead Free | Lead Free |
| Leakage Current | 1µA |
| Length | 2.9mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | ACTIVE |
| Max Breakdown Voltage | 18.5V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 225mW |
| Max Reverse Leakage Current | 1µA |
| Max Surge Current | 10A |
| Min Breakdown Voltage | 16.7V |
| Min Operating Temperature | -55°C |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Lines | 1 |
| Number of Pins | 3 |
| Number of Terminals | 3 |
| Number of Unidirectional Channels | 1 |
| Operating Supply Voltage | 15V |
| Packaging | Tape and Reel |
| Peak Pulse Current | 5A |
| Peak Pulse Power | 300W |
| Peak Reverse Current | 1µA |
| Polarity | Unidirectional |
| Power Dissipation | 300W |
| Power Line Protection | No |
| Power Rating | 300W |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Breakdown Voltage | 16.7V |
| Reverse Standoff Voltage | 15V |
| RoHS | Compliant |
| Schedule B | 8536300000|8536300000|8536300000|8536300000|8536300000 |
| Termination | SMD/SMT |
| Test Current | 1mA |
| Voltage Rating (DC) | 15V |
| Width | 1.4mm |
| Working Voltage | 15V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
