SMF12AT1 - onsemi
SOD-123F 1 Surface Mount 1 Zener Tvs Diode 13.3V 10.1A 200W -55C~150C TJ
Technical Details
| Breakdown Voltage | 14V |
| China RoHS | Non-Compliant |
| Clamping Voltage | 19.9V |
| Composition | Zener |
| Contact Plating | Tin |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Forward Voltage | 3.5V |
| Height | 1mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2003-03-01 |
| Lead Free | Contains Lead |
| Length | 2.9mm |
| Lifecycle Status | Obsolete |
| Max Breakdown Voltage | 14.7V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 385mW |
| Max Surge Current | 10.1A |
| Min Breakdown Voltage | 13.3V |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Terminals | 2 |
| Number of Unidirectional Channels | 1 |
| Operating Supply Voltage | 12V |
| Packaging | Tape & Reel (TR) |
| Peak Pulse Current | 10.1A |
| Peak Pulse Power | 1kW |
| Peak Reverse Current | 2.5µA |
| Polarity | Unidirectional |
| Power Line Protection | No |
| Power Rating | 200W |
| REACH SVHC | No |
| Reverse Standoff Voltage | 12V |
| RoHS | Compliant |
| Voltage Rating (DC) | 12V |
| Width | 1.8mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
Images
Rochester Electronics
Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| Rochester Electronics |
US: 2815
|
$ | 0.251 | 0.2083 | 0.1857 | |||||
| Verical |
US: 2815
|
$ | 0.2321 | |||||||
