Technical Details
| Breakdown Voltage | 29.3V |
| Case/Package | SC |
| China RoHS | Compliant |
| Clamping Voltage | 44V |
| Composition | Zener |
| Contact Plating | Tin |
| Country of Origin | Malaysia |
| Depth | 1.25mm |
| Direction | Unidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Common Anode |
| ESD Protection | Yes |
| Height | 1mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2003-04-30 |
| Lead Free | Lead Free |
| Leakage Current | 1µA |
| Length | 2mm |
| Lifecycle Status | Obsolete |
| Manufacturer Lifecycle Status | OBSOLETE |
| Max Breakdown Voltage | 32V |
| Max Operating Temperature | 125°C |
| Max Reverse Leakage Current | 1µA |
| Max Surge Current | 2.5A |
| Min Breakdown Voltage | 26.7V |
| Min Operating Temperature | -40°C |
| Number of Channels | 5 |
| Number of Elements | 5 |
| Number of Pins | 6 |
| Number of Terminals | 6 |
| Number of Unidirectional Channels | 5 |
| Operating Supply Voltage | 24V |
| Packaging | Tape and Reel |
| Peak Pulse Current | 2.5A |
| Peak Pulse Power | 100W |
| Peak Reverse Current | 1µA |
| Polarity | Unidirectional |
| Power Dissipation | 100W |
| Power Line Protection | No |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Standoff Voltage | 24V |
| RoHS | Compliant |
| Termination | SMD/SMT |
| Test Current | 1mA |
| Width | 1.35mm |
| Working Voltage | 24V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
Images
Farnell
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| onsemi | Obsolete | ||
| Protek Devices | Production | ||
| Protek Devices | Production | ||
| MCC | Production | ||
| NXP Semiconductors | Obsolete | ||
| Littelfuse | Production | ||
| Infineon | Obsolete | ||
| onsemi | Obsolete | ||
| Protek Devices | Production | ||
| onsemi | Obsolete |
