SMF60AT1G - onsemi
Trans Voltage Suppressor Diode, 1000W, 60V V(RWM), Unidirectional, 1 Element, Silicon
Technical Details
| Breakdown Voltage | 70.2V |
| China RoHS | Non-Compliant |
| Clamping Voltage | 96.8V |
| Composition | Zener |
| Contact Plating | Tin |
| Depth | 1.65mm |
| Direction | Unidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Forward Voltage | 3.5V |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 2003-03-19 |
| Lead Free | Lead Free |
| Leakage Current | 400µA |
| Length | 2.7mm |
| Lifecycle Status | Obsolete |
| Max Breakdown Voltage | 73.7V |
| Max Operating Temperature | 150°C |
| Max Power Dissipation | 385mW |
| Max Surge Current | 19.4A |
| Min Breakdown Voltage | 66.7V |
| Min Operating Temperature | -55°C |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Number of Unidirectional Channels | 1 |
| Operating Supply Voltage | 6V |
| Peak Pulse Current | 19.4A |
| Peak Pulse Power | 1kW |
| Peak Reverse Current | 1µA |
| Polarity | Unidirectional |
| Power Line Protection | No |
| Power Rating | 175W |
| Radiation Hardening | No |
| REACH SVHC | No |
| Reverse Standoff Voltage | 60V |
| RoHS | Compliant |
| Voltage Rating (DC) | 60V |
| Width | 1.8mm |
| Working Voltage | 6V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : No
