Technical Details
| Case/Package | TO-46-2 |
| Country of Origin | Mexico |
| Export Control Classification Number (ECCN) Code | 3A001.a.2.b |
| Forward Current | 100mA |
| Forward Voltage | 1.8V |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Introduction Date | 1993-01-01 |
| Lead Free | Lead Free |
| Lens Style | Circular |
| Lifecycle Status | Production |
| Max Operating Temperature | 125°C |
| Min Operating Temperature | -65°C |
| Mount | Through Hole |
| Number of Circuits | 1 |
| Number of Pins | 2 |
| Orientation | Top View |
| Output Power | 5mW |
| Packaging | Bulk |
| Peak Wavelength | 935nm |
| Power Rating | 200mW |
| REACH SVHC | Yes |
| Reverse Voltage | 2V |
| Rise Time | 1µs |
| RoHS | Compliant |
| Shape | Cylindrical |
| Viewing Angle | 50° |
| Wavelength | 935nm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
