Technical Details
| China RoHS | Compliant |
| Color | White |
| Forward Current | 30mA |
| Forward Voltage | 3.4V |
| Height | 1.2mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Introduction Date | 2014-02-21 |
| Length | 2.2mm |
| Lens Style | Diffused |
| Lifecycle Status | Production |
| Luminous Flux | 6.88lm |
| Luminous Intensity | 1.8cd |
| Max Operating Temperature | 110°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of Terminals | 2 |
| Packaging | Tape & Reel (TR) |
| REACH SVHC | Yes |
| Reverse Voltage | 1.2V |
| RoHS | Compliant |
| Shape | Rectangular |
| Terminal Pitch | 1.8mm |
| Viewing Angle | 120° |
| Width | 1.8mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
Images
Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| Arrow Electronics |
US: 189000
|
$ | 0.113 | |||||||
| Mouser |
US: 6573
|
$ | 0.55 | 0.378 | 0.378 | 0.272 | 0.212 | 0.133 | ||
| TTI |
US: 0
|
$ | 0.13 | |||||||
| Avnet |
US: 0
|
$ | 0.1316 | |||||||
