Technical Details
| Case/Package | PLCC |
| Color | Red |
| Depth | 3mm |
| Dominant Wavelength | 633nm |
| Forward Current | 30mA |
| Forward Voltage | 2.3V |
| Height | 1.8mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Illumination Color | Red |
| Introduction Date | 2018-03-29 |
| Lead Free | Lead Free |
| Length | 3.2mm |
| Lens Color | Colorless |
| Lens Style | Circular, Colorless, Diffused |
| Lens Transparency | Clear |
| Lifecycle Status | Production |
| Luminous Flux | 380mlm |
| Luminous Intensity | 71mcd |
| Max Operating Temperature | 100°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of LEDs | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Peak Wavelength | 645nm |
| Power Dissipation | 80W |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Voltage | 12V |
| RoHS | Compliant |
| Shape | Round |
| Terminal Pitch | 3mm |
| Test Current | 20mA |
| Viewing Angle | 120° |
| Wavelength | 645nm |
| Width | 2.8mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
