Technical Details
| Case/Package | Radial |
| China RoHS | Compliant |
| Forward Current | 100mA |
| Forward Voltage | 1.9V |
| Height | 8.2mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Introduction Date | 2014-05-20 |
| Length | 5.5mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 100°C |
| Min Operating Temperature | -40°C |
| Number of Circuits | 1 |
| Output Power | 75mW |
| Packaging | Bulk |
| Peak Wavelength | 860nm |
| Power Dissipation | 200mW |
| REACH SVHC | Yes |
| Reverse Voltage | 5V |
| Rise Time | 12ns |
| RoHS | Compliant |
| Schedule B | 8541402000, 8541402000|8541402000|8541402000|8541402000|8541402000 |
| Shape | Round |
| Viewing Angle | 10° |
| Wavelength | 860nm |
| Width | 5.5mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
Images
TME
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Everlight | Production | ||
| Honeywell | Obsolete | ||
| Toshiba | Obsolete | ||
| Lite-On | Production | ||
| Excelitas Technology | Production | ||
| Kingbright | Production | ||
| Stanley Electric | Obsolete | ||
| Hamamatsu Photonics | Unknown | ||
| Panasonic | Obsolete | ||
| Vishay | Obsolete |
