EVP-AFKB65 - Panasonic
Switch Tactile N.O. SPST Round Button J-Bend 0.02A 15VDC 1.3N SMD T/R
Technical Details
| Case/Package | SMD/SMT |
| Color | Black |
| Contact Current Rating | 20mA |
| Contact Resistance | 500mΩ |
| Country of Origin | Japan, Mainland China |
| Current Rating | 50mA |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 750µm |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.70.00 |
| Illumination Type | Illuminated |
| Introduction Date | 2012-12-12 |
| Life (Cycles) | 100kcycles |
| Lifecycle Status | Production |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Positions | 2 |
| Operating Force | 1.3N |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Termination | Gull Wing |
| Throw Configuration | SPST |
| Voltage Rating (DC) | 15V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
