EVP-AXBA1A - Panasonic
Switch Tactile N.O. SPDT Flat Button J-Bend 0.02A 15V DC 100000Cycle 2N SMD Embossed T/R
Technical Details
| Color | Black |
| Contact Current Rating | 20mA |
| Contact Resistance | 500mΩ |
| Current Rating | 50mA |
| Height | 850µm |
| Illumination Type | Illuminated, Non-Illuminated |
| Life (Cycles) | 100kcycles |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (DC) | 15V |
| Mechanical Life | 100kcycles |
| Min Operating Temperature | -20°C |
| Mount | Surface Mount |
| Operating Force | 2N |
| Radiation Hardening | No |
| REACH SVHC | Unknown |
| RoHS | Compliant |
| Schedule B | 8536509065, 8536509065|8536509065|8536509065|8536509065|8536509065 |
| Switch Function | Off-Mom-Mom |
| Switch Travel | 160µm |
| Termination | SMD/SMT |
| Throw Configuration | SPDT, SPST |
| Voltage Rating (DC) | 15V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Unknown
