EVQ-P0N02B - Panasonic
Switch Tactile ON OFF SPST Round Button J-Bend 0.02A 15VDC 0.6N SMD Embossed T/R
Technical Details
| Actuator Length | 700µm |
| Color | Blue |
| Contact Current Rating | 20mA |
| Contact Plating | Gold, Silver |
| Contact Resistance | 100mΩ |
| Current Rating | 20mA |
| Depth | 6.6mm |
| Electrical Life | 2Mcycles |
| Height | 1.8mm |
| Illumination Type | Illuminated, Non-Illuminated |
| Lead Free | Lead Free |
| Length | 6.5mm |
| Life (Cycles) | 2Mcycles |
| Lifecycle Status | Production |
| Max Current Rating | 20mA |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (DC) | 15V |
| Mechanical Life | 2Mcycles |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Positions | 1 |
| Operating Force | 600mN |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Switch Function | Off-Mom |
| Switch Travel | 300µm |
| Termination | J-Bend |
| Thickness | 1.8mm |
| Throw Configuration | SPST |
| Voltage Rating (DC) | 15V |
| Width | 6mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
