EVQ-PUD02K - Panasonic
Switch Tactile N.O. SPST Rectangular Button J-Bend 0.05A 12VDC 2.2N SMD Embossed Tape
Technical Details
| Actuator Length | 990.6µm |
| Color | Black |
| Contact Current Rating | 50mA |
| Contact Plating | Gold, Silver |
| Contact Resistance | 500mΩ |
| Current Rating | 50mA |
| Depth | 4.5mm |
| Electrical Life | 100kcycles |
| Height | 1.65mm |
| Illumination Type | Illuminated, Non-Illuminated |
| Insulation Resistance | 100MΩ |
| Lead Free | Lead Free |
| Length | 4.7mm |
| Life (Cycles) | 100kcycles |
| Lifecycle Status | Production |
| Max Current Rating | 50mA |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (DC) | 12V |
| Mechanical Life | 100kcycles |
| Min Operating Temperature | -20°C |
| Mount | Surface Mount |
| Number of Positions | 1 |
| Operating Force | 3N |
| Orientation | Right Angle |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Switch Function | Off-Mom |
| Switch Travel | 300µm |
| Termination | J-Bend |
| Throw Configuration | SPST |
| Voltage Rating (DC) | 12V |
| Width | 3.5mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
Images
Onlinecomponents.com
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Panasonic | Production | ||
| Panasonic | Unknown | ||
| Panasonic | Production | ||
| Panasonic | Production | ||
| Wurth Elektronik | Unknown | ||
| Wurth Elektronik | Unknown | ||
| Wurth Elektronik | Unknown | ||
| Wurth Elektronik | Unknown | ||
| C&K Components | Production | ||
| C&K Components | Production |
