EVQ-PUJ02K - Panasonic
Switch Tactile N.O. SPST Rectangular Button Gull Wing 0.05A 12VDC 1.6N SMD Embossed Tape
Technical Details
| Actuator Length | 1mm |
| Color | Black |
| Contact Current Rating | 50mA |
| Contact Plating | Silver |
| Contact Resistance | 500mΩ |
| Current Rating | 20mA |
| Depth | 4.5mm |
| Electrical Life | 100kcycles |
| Height | 1.95mm |
| Illumination Type | Illuminated, Non-Illuminated |
| Lead Free | Lead Free |
| Length | 6.4mm |
| Life (Cycles) | 100kcycles |
| Max Current Rating | 50mA |
| Max Operating Temperature | 70°C |
| Max Voltage Rating (DC) | 12V |
| Mechanical Life | 100kcycles |
| Min Operating Temperature | -20°C |
| Mount | Surface Mount |
| Operating Force | 1.6N |
| Radiation Hardening | No |
| REACH SVHC | Unknown |
| RoHS | Compliant |
| Switch Function | Off-Mom |
| Switch Travel | 300µm |
| Termination | Gull Wing |
| Throw Configuration | SPST |
| Voltage Rating (DC) | 12V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Unknown
Images
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Knitter Switch | Unknown | ||
| E-Switch | Production | ||
| E-Switch | Production | ||
| C&K Components | Production | ||
| APEM | Production | ||
| Multicomp | Production | ||
| Multicomp | Production | ||
| E-Switch | Production | ||
| Schurter | Production | ||
| E-Switch | Production |
