EVQ-PV205K - Panasonic
Switch Tactile N.O. SPST Round Button PC Pins 0.05A 12VDC 1.6N Thru-Hole Radial T/R
Technical Details
| Case/Package | Radial |
| Contact Current Rating | 50mA |
| Contact Resistance | 100mΩ |
| Height | 5.2mm |
| Illumination Type | Non-Illuminated |
| Lead Free | Lead Free |
| Life (Cycles) | 100kcycles |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (DC) | 12V |
| Mechanical Life | 100kcycles |
| Min Operating Temperature | -30°C |
| Mount | Through Hole |
| Operating Force | 1.6N |
| Packaging | Tape & Box (TB) |
| Radiation Hardening | No |
| RoHS | Compliant |
| Schedule B | 8536509065, 8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|8536509065|85 |
| Switch Function | Off-Mom |
| Switch Travel | 1.3mm |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Voltage Rating (DC) | 12V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
Images
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Knitter Switch | Unknown | ||
| E-Switch | Production | ||
| E-Switch | Production | ||
| C&K Components | Production | ||
| APEM | Production | ||
| Multicomp | Production | ||
| Multicomp | Production | ||
| E-Switch | Production | ||
| Schurter | Production | ||
| E-Switch | Production |
