EVQP4MB3K - Panasonic
Switch Tactile N.O. SPST Round Button J-Bend 0.02A 15VDC 5N SMD Embossed T/R
Technical Details
| Case/Package | SMD/SMT |
| Color | Black |
| Contact Current Rating | 20mA |
| Contact Resistance | 100mΩ |
| Current Rating | 20mA |
| Depth | 3.4mm |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Electrical Life | 200kcycles |
| Height | 2.55mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.90.40 |
| Illumination Type | Non-Illuminated |
| Insulation Resistance | 100MΩ |
| Introduction Date | 2012-02-01 |
| Lead Free | Lead Free |
| Length | 6.2mm |
| Life (Cycles) | 200kcycles |
| Lifecycle Status | Production |
| Max Current Rating | 20mA |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (DC) | 15V |
| Mechanical Life | 200kcycles |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Positions | 1 |
| Operating Force | 5N |
| Orientation | Right Angle |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Switch Function | Off-Mom |
| Switch Travel | 700µm |
| Termination | J-Bend |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 250V |
| Voltage Rating (DC) | 15V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
