Technical Details
| Case/Package | 1208 |
| Case Code (Imperial) | 1208 |
| Case Code (Metric) | 3020 |
| Color | Red |
| Dominant Wavelength | 660nm |
| Forward Current | 15mA |
| Forward Voltage | 2.6V |
| Height | 1.4mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Introduction Date | 1997-01-01 |
| Lead Free | Lead Free |
| Length | 3mm |
| Lens Style | Clear |
| Lifecycle Status | Obsolete |
| Luminous Intensity | 9mcd |
| Max Operating Temperature | 80°C |
| Min Operating Temperature | -25°C |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of LEDs | 1 |
| Number of Pins | 2 |
| Number of Terminals | 2 |
| Packaging | Bulk |
| Peak Wavelength | 660nm |
| REACH SVHC | No |
| Reverse Voltage | 3V |
| RoHS | Compliant |
| Shape | Rectangular |
| Test Current | 10mA |
| Viewing Angle | 0° |
| Wavelength | 660nm |
| Width | 2mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
