Technical Details
| Export Control Classification Number (ECCN) Code | EAR99 |
| Gain | 13dB |
| Height | 1mm |
| Impedance | 50Ω |
| Introduction Date | 2018-08-29 |
| Lifecycle Status | Production |
| Max Frequency | 26.5GHz |
| Max Operating Temperature | 85°C |
| Max Power Dissipation | 495mW |
| Max Supply Current | 110mA |
| Max Supply Voltage | 7V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 4V |
| Mount | Surface Mount |
| Noise Figure | 6dB |
| Nominal Supply Current | 74mA |
| Number of Circuits | 1 |
| Number of Terminals | 24 |
| P1dB | 15dBm |
| REACH SVHC | Yes |
| RoHS | Compliant |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
