DWM1004C - Qorvo
DW1000 Series 6.5 GHz 6.8 Mbps Ultra Wideband Transceiver IC Based Module
Technical Details
| Bandwidth | 3.496GHz |
| Current - Receiving | 155mA |
| Current - Transmitting | 114mA |
| Data Rate | 6.8Mbps |
| Export Control Classification Number (ECCN) Code | 5A992.C |
| Height | 3mm |
| Interface | I2C, SPI, UART |
| Introduction Date | 2020-10-29 |
| Lifecycle Status | Obsolete |
| Max Frequency | 6.74GHz |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 3.6V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.8V |
| Nominal Supply Current | 16mA |
| Number of GPIO | 21 |
| REACH SVHC | Yes |
| RoHS | Compliant |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
Images
RFMW
Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| Mouser |
US: 84
|
$ | 20.08 | 20.08 | 20.02 | 20.02 | 19.56 | 19.56 | ||
| RFMW |
US: 0
|
$ | ||||||||
Non-Authorized Distributors
| Distributor | SKU | Stock | USD | 1 | 10 | 50 | 100 | 1000 | 10000 | Buy |
|---|---|---|---|---|---|---|---|---|---|---|
| Worldway Electronics |
HK: 27347
|
$ | 4.0071 | 4.0071 | 3.8844 | 3.68 | 3.68 | |||
| Sourcengine |
US: 27436
|
$ | ||||||||
