BZX84C5V1T1 - Rectron
Zener Diode, 5.1V V(Z), 5.882%, 0.3W, Silicon, Unidirectional, SOT-23, 3 PIN
Technical Details
| Case/Package | SOT-23 |
| Country of Origin | Mainland China |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Single |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Impedance | 60Ω |
| Introduction Date | 1999-05-11 |
| Lifecycle Status | Production |
| Max Operating Temperature | 125°C |
| Max Power Dissipation | 300mW |
| Max Reverse Leakage Current | 2µA |
| Min Operating Temperature | -55°C |
| Number of Elements | 1 |
| Number of Terminals | 3 |
| Polarity | Unidirectional |
| Power Dissipation | 300mW |
| REACH SVHC | Yes |
| Reference Voltage | 5.1V |
| RoHS | Compliant |
| Voltage Tolerance | 5.882% |
| Zener Current | 5mA |
| Zener Voltage | 5.1V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
Images
