EMX2T2R - ROHM
Small Signal Bipolar Transistor, 0.15A I(C), 50V V(BR)CEO, 2-Element, NPN, Silicon
Technical Details
| Collector Base Voltage (VCBO) | 60V |
| Collector Emitter Breakdown Voltage | 50V |
| Collector Emitter Saturation Voltage | 400mV |
| Collector Emitter Voltage (VCEO) | 50V |
| Contact Plating | Copper, Tin |
| Continuous Collector Current | 150mA |
| Current Rating | 150mA |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Dual |
| Emitter Base Voltage (VEBO) | 7V |
| Gain Bandwidth Product | 180MHz |
| hFE Min | 120 |
| Introduction Date | 2000-05-29 |
| Lead Free | Lead Free |
| Lifecycle Status | NRND |
| Max Breakdown Voltage | 50V |
| Max Collector Current | 150mA |
| Max Operating Temperature | 150°C |
| Max Output Current | 100mA |
| Max Power Dissipation | 150mW |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Elements | 2 |
| Number of Pins | 6 |
| Number of Terminals | 6 |
| Operating Supply Voltage | 50V |
| Polarity | NPN |
| Power Dissipation | 150mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Termination | SMD/SMT |
| Transition Frequency | 180MHz |
| Voltage Rating (DC) | 50V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
