1241.1624.5 - Schurter
PMS Series SPST 42 V Top Actuated Green Non-Illuminated IP40 Pushbutton Switch
Technical Details
| Actuator Length | 7.85mm |
| Actuator Material | Polyphenylene |
| China RoHS | Compliant |
| Contact Current Rating | 50mA |
| Contact Plating | Tin |
| Contact Resistance | 50mΩ |
| Current Rating | 50mA |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Height | 7.6mm |
| Harmonized Tariff Schedule (HTS) Code | 8536.50.70.00 |
| Illumination Type | Non-Illuminated |
| Introduction Date | 2002-01-29 |
| Life (Cycles) | 1Mcycles |
| Lifecycle Status | Production |
| Max Current Rating | 50mA |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (AC) | 30V |
| Max Voltage Rating (DC) | 42V |
| Mechanical Life | 1Mcycles |
| Min Operating Temperature | -40°C |
| Mount | Through Hole |
| Number of Positions | 1 |
| Operating Force | 1.8N |
| Orientation | Straight |
| Radiation Hardening | No |
| Ratings | IP40 |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Switch Function | Off-Mom |
| Switch Travel | 350µm |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 30V |
| Voltage Rating (DC) | 42V |
| Weight | 1.400013g |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
