3402.0016.11 - Schurter
Fuse Chip Fast Acting 4A 63V SMD Solder Pad 7.4 X 3.1mm Thermoplastic Plastic Bag
Technical Details
| Approvals | cURus |
| Body Material | Thermoplastic |
| Case/Package | SMD/SMT |
| China RoHS | Compliant |
| Contact Plating | Tin |
| Current | 4A |
| Current Rating | 4A |
| Depth | 3.1mm |
| Flammability Rating | UL94 V-0 |
| Height | 2.6mm |
| Housing Material | Thermoplastic |
| Lead Free | Lead Free |
| Length | 7.4mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 125°C |
| Max Voltage Rating (AC) | 63V |
| Max Voltage Rating (DC) | 63V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Pins | 2 |
| Packaging | Bulk |
| Power Dissipation | 560mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Terminal Material | Copper |
| Voltage Rating | 63V |
| Voltage Rating (AC) | 63V |
| Voltage Rating (DC) | 63V |
| Weight | 99.988768mg |
| Width | 3.1mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
Images
Sager Electronics
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| NXP Semiconductors | Production | ||
| NXP Semiconductors | Production | ||
| Schurter | Production | ||
| Schurter | Production | ||
| Preci-Dip | Production | ||
| Preci-Dip | Production | ||
| Harwin | Obsolete | ||
| Preci-Dip | Production | ||
| Harwin | Production | ||
| Harwin | Obsolete |
