PFRA.090.2 - Schurter
Radial Resettable Fuse, PPTC, PFRA, 60 VDC, 900 mA, 1.8 A, 7.2 s, Round
Technical Details
| Approvals | CSA, UL |
| Case/Package | Radial |
| China RoHS | Compliant |
| Current Rating | 40A |
| Diameter | 11.7mm |
| Height | 16.7mm |
| Hold Current | 900mA |
| Lead Free | Lead Free |
| Lead Pitch | 5.8mm |
| Length | 11.7mm |
| Lifecycle Status | Production |
| Max Current Rating | 40A |
| Max Operating Temperature | 85°C |
| Max Voltage Rating (DC) | 60V |
| Min Operating Temperature | -40°C |
| Number of Terminals | 2 |
| Power Dissipation | 1W |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Resistance | 140mΩ |
| RoHS | Compliant |
| Termination | Radial |
| Time to Trip | 7.2s |
| Trip Current | 1.8A |
| Weight | 430.005567mg |
| Width | 3.1mm |
| Working Voltage | 60V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
Images
Sager Electronics
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Littelfuse | Production | ||
| Schurter | Production | ||
| Schurter | Production | ||
| Bourns | Obsolete | ||
| Bourns | Production | ||
| TE Connectivity / Raychem | Obsolete | ||
| Littelfuse | Production | ||
| Littelfuse | Production | ||
| Littelfuse | Production | ||
| Littelfuse | Production |
