A2490 - Sensata /Crydom
Relay; SSR; Zero-Switching; SPST-NO; Cur-Rtg 90A; Ctrl-V 90-280AC; Vol-Rtg 24-280AC
Technical Details
| Approvals | CE, CSA, UL, VDE |
| Current Rating | 90A |
| Data Polarity | AC |
| Depth | 45.7mm |
| Forward Current | 10mA |
| Height | 22.9mm |
| Isolation Voltage | 4000Vrms |
| Lead Free | Lead Free |
| Length | 58.4mm |
| Load Current | 90A |
| Max Length | 58.4mm |
| Max Operating Temperature | 80°C |
| Max Supply Voltage (AC) | 280V |
| Max Voltage Rating (AC) | 280V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage (AC) | 24V |
| Mount | Chassis Mount, Panel, Screw, Surface Mount |
| Number of Elements | 1 |
| Number of Pins | 4 |
| Operating Supply Voltage | 280V |
| Output Current | 90A |
| REACH SVHC | Yes |
| Relay Type | Relay |
| RoHS | Compliant |
| Termination | Screw |
| Throw Configuration | SPST |
| Voltage Rating (AC) | 280V |
| Width | 45.7mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
Images
Onlinecomponents.com
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Schneider Electric | Unknown | ||
| Sensata /Crydom | Unknown | ||
| Magnecraft | Unknown | ||
| Opto 22 | Unknown | ||
| Magnecraft | Unknown | ||
| Sensata /Crydom | Unknown | ||
| Schneider Electric | Unknown | ||
| Magnecraft | Unknown | ||
| Magnecraft | Unknown | ||
| Opto 22 | Unknown |
