Technical Details
| Case/Package | Axial |
| Coil Current | 27.8mA |
| Coil Power | 139mW |
| Coil Resistance | 160Ω |
| Coil Type | Non-Latching |
| Coil Voltage (DC) | 5V |
| Contact Current Rating | 700mA |
| Contact Resistance | 80mΩ |
| Length | 22.86mm |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | PCB, Through Hole |
| Operate Time | 1ms |
| Packaging | Bulk |
| REACH SVHC | No |
| Relay Type | Reed |
| Release Time | 500µs |
| RoHS | Compliant |
| Switching Current | 700mA |
| Termination | Axial |
| Throw Configuration | SPST |
Compliance
RoHS : Unconfirmed
REACH SVHC : No
