Technical Details
| Case/Package | Radial |
| Depth | 1.5mm |
| Forward Current | 50mA |
| Forward Voltage | 1.2V |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Introduction Date | 1994-01-01 |
| Lead Free | Lead Free |
| Lead Length | 17.5mm |
| Lead Pitch | 2.54mm |
| Length | 3mm |
| Lens Style | Circular, Diffused, Round |
| Lifecycle Status | Production |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -25°C |
| Mount | Through Hole |
| Number of Circuits | 1 |
| Number of Elements | 1 |
| Number of LEDs | 1 |
| Number of Pins | 2 |
| Orientation | Side View |
| Output Power | 1.6mW |
| Packaging | Bulk |
| Peak Wavelength | 950nm |
| Power Dissipation | 75mW |
| Power Rating | 75mW |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Voltage | 6V |
| RoHS | Compliant |
| Shape | Round |
| Test Current | 20mA |
| Wavelength | 950nm |
| Width | 3mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
