Technical Details
| Case/Package | SIP |
| Depth | 5.5mm |
| Forward Current | 50mA |
| Height | 24.6mm |
| Input Current | 50mA |
| Isolation Voltage | 4000Vrms |
| Lead Free | Lead Free |
| Length | 18.5mm |
| Lifecycle Status | Obsolete |
| Load Current | 16A |
| Max Input Current | 50mA |
| Max Input Voltage | 1.4V |
| Max Operating Temperature | 100°C |
| Max Output Current | 16A |
| Max Output Voltage | 600V |
| Min Operating Temperature | -25°C |
| Mount | PCB, Through Hole |
| Nominal Input Voltage | 1.4V |
| Number of Elements | 1 |
| Number of Pins | 4 |
| Output Current | 16A |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Relay Type | Relay |
| RoHS | Compliant |
| Termination | PC Pin |
| Throw Configuration | SPST |
| Turn-On Delay Time | 10ms |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
