C8051F703-GQ - Silicon Lab
Mixed Signal Isp Flash Mcu Family Microcontroller, 8-BIT, Flash, 8051 Cpu, 25MHZ, Cmos, PQFP64
Technical Details
| Case/Package | TQFP |
| Contact Plating | Tin |
| Core Architecture | 8051 |
| Data Bus Width | 8b |
| Frequency | 25MHz |
| Height - Seated (Max) | 1.2mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.31.00.15 |
| Introduction Date | 2009-02-13 |
| Length | 10mm |
| Lifecycle Status | Obsolete |
| Max Frequency | 25MHz |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 3.6V |
| Memory Size | 16kB |
| Memory Type | FLASH |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 1.8V |
| Number of Channels | 3 |
| Number of I/Os | 54 |
| Number of Pins | 64 |
| Number of Programmable I/O | 54 |
| Number of Terminals | 64 |
| Number of Timers/Counters | 4 |
| Operating Supply Voltage | 3V |
| Oscillator Type | Internal |
| Peripherals | POR, PWM, WDT |
| RAM Size | 512B |
| RoHS | Compliant |
| Temperature Grade | Industrial |
| Terminal Pitch | 500µm |
| Watchdog Timer | Yes |
| Width | 10mm |
Compliance
RoHS : Unconfirmed
