Technical Details
| Case/Package | LGA |
| Core Architecture | 8051 |
| Current - Receiving | 18.5mA |
| Current - Transmitting | 85mA |
| Data Bus Width | 8b |
| Data Rate | 256kbps |
| Export Control Classification Number (ECCN) Code | 3A991.a.2 |
| Frequency | 960MHz |
| Height - Seated (Max) | 940µm |
| Harmonized Tariff Schedule (HTS) Code | 8542.31.00.15 |
| Interface | I2C, SMBus, SPI, UART |
| Introduction Date | 2011-11-11 |
| Length | 8mm |
| Lifecycle Status | Production |
| Max Frequency | 25MHz |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 3.8V |
| Memory Size | 16kB |
| Memory Type | FLASH |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 1.8V |
| Number of GPIO | 53 |
| Number of I/Os | 53 |
| Number of Pins | 85 |
| Number of Programmable I/O | 53 |
| Number of Terminals | 85 |
| Number of Timers/Counters | 4 |
| Operating Supply Voltage | 3.3V |
| Radiation Hardening | No |
| RAM Size | 4.3kB |
| RoHS | Compliant |
| Sensitivity (dBm) | -121dBm |
| Temperature Grade | Industrial |
| Terminal Pitch | 500µm |
| Watchdog Timer | Yes |
| Width | 6mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
