SI3453A-B02-GMR - Silicon Lab
Quad Poe Pse Port Controller (auto, Endpoint, DC Disconnect)
Technical Details
| Case/Package | QFN |
| Height - Seated (Max) | 900µm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.01 |
| Introduction Date | 2011-08-31 |
| Length | 6mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 85°C |
| Max Output Power | 40W |
| Max Power Dissipation | 40W |
| Min Operating Temperature | -40°C |
| Number of Channels | 4 |
| Number of Circuits | 1 |
| Number of Pins | 40 |
| Number of Terminals | 40 |
| Operating Supply Current | 4mA |
| Operating Supply Voltage | 3.3V |
| Packaging | Tape and Reel |
| RoHS | Compliant |
| Temperature Grade | Industrial |
| Terminal Pitch | 500µm |
| Width | 6mm |
Compliance
RoHS : Unconfirmed
Images
