Technical Details
| Case/Package | QFN |
| China RoHS | Compliant |
| Current - Receiving | 10.5mA |
| Depth | 3mm |
| Frequency | 108MHz |
| Height - Seated (Max) | 600µm |
| Length | 3mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | FULL PRODUCTION |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -20°C |
| Min Supply Voltage | 2.7V |
| Number of Circuits | 1 |
| Number of Pins | 20 |
| Number of Terminals | 20 |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8542390000 |
| Signal to Noise Ratio (SNR) | 58dB |
| Terminal Pitch | 500µm |
| Width | 3mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
