Technical Details
| Case/Package | SOP |
| Channel Type | Unidirectional |
| China RoHS | Compliant |
| Data Rate | 1Mbps |
| Height - Seated (Max) | 2.65mm |
| Introduction Date | 2009-01-23 |
| Length | 10.3mm |
| Max Data Rate | 1 |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 5.5V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.7V |
| Nominal Supply Current | 4.5mA |
| Number of Channels | 4 |
| Number of Circuits | 1 |
| Number of Pins | 16 |
| Number of Terminals | 16 |
| Power Dissipation | 275mW |
| Propagation Delay | 35ns |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8542390000 |
| Temperature Grade | Automotive |
| Terminal Pitch | 1.27mm |
| Turn-On Delay Time | 35ns |
| Weight | 547.51434mg |
| Width | 7.5mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
