SI8711BC-B-IS - Silicon Lab
Digital Isolator, 1, 60 ns, 3 V, 30 V, NSOIC, 8 RoHS Compliant: Yes
Technical Details
| Case/Package | SOIC |
| Channel Type | Unidirectional |
| China RoHS | Compliant |
| Data Rate | 15Mbps |
| Depth | 1.55mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.39.00.01 |
| Introduction Date | 2012-09-24 |
| Isolated Power | No |
| Isolation Voltage | 3750Vrms |
| Length | 5mm |
| Lifecycle Status | Production |
| Manufacturer Lifecycle Status | FULL PRODUCTION |
| Max Data Rate | 15 |
| Max Input Current | 30mA |
| Max Operating Temperature | 125°C |
| Max Supply Voltage | 30V |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 3V |
| Nominal Supply Current | 1.7mA |
| Number of Channels | 1 |
| Number of Pins | 8 |
| Packaging | Cut Tape |
| Power Dissipation | 140mW |
| Propagation Delay | 60ns |
| Pulse Width Distortion (PWD) | 20ns |
| REACH SVHC | Yes |
| Rise Time | 15ns |
| RoHS | Compliant |
| Type | General Purpose |
| Width | 4mm |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
Images
TME
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Silicon Lab | Production | ||
| Silicon Lab | Production | ||
| Silicon Lab | Production | ||
| Silicon Lab | Production | ||
| Silicon Lab | Production | ||
| Silicon Lab | Production | ||
| Silicon Lab | Production | ||
| Silicon Lab | Production | ||
| Silicon Lab | Production | ||
| Silicon Lab | Production |
