SST39VF1601C-70-4I-EKE - Microchip
MICROCHIP SST39VF1601C-70-4I-EKE Flash Memory, 16 Mbit, 1M x 16bit, 5 MHz, Parallel, TSOP, 48 Pins
Technical Details
| Access Time | 70ns |
| Access Time-Max | 70ns |
| Address Bus Width | 20b |
| Case/Package | TSOP |
| Data Bus Width | 16b |
| Density | 16Mb |
| Frequency | 5MHz |
| Height | 1.05mm |
| Interface | Parallel |
| Lead Free | Lead Free |
| Length | 12.2mm |
| Max Operating Temperature | 85°C |
| Max Supply Voltage | 3.6V |
| Memory Size | 16Mb |
| Memory Type | NOR, , FLASH, NAND |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.7V |
| Number of Pins | 48 |
| Operating Supply Voltage | 3.3V |
| Organization | 1M x 16 |
| Package Quantity | 96 |
| Packaging | Tray |
| Radiation Hardening | No |
| Reach SVHC Compliant | No |
| RoHS Compliant | No |
| Series | SST39 MPF™ |
| Supply Current | 18mA |
| Supply Voltage-Nom | 3.6V |
| Sync/Async | Asynchronous |
| Width | 18.5mm |
| Word Size | 16b |
Compliance
Images
Arrow Electronics
Newark
Allied Electronics
Element14
Rs
microchipDIRECT
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| Microchip | Volume Production | ||
| Microchip | Not Recommended for New Design | ||
| Microchip | Volume Production | ||
| Spansion | Volume Production | ||
| Micron Technology | End of Life | ||
| Micron Technology | Obsolete | ||
| Micron Technology | Obsolete | ||
| Micron Technology | End of Life | ||
| Spansion | Volume Production | ||
| Spansion | Volume Production |
