RNCP0805FTD180R - Stackpole Electronics
Fixed Resistor, Thin Film, 0.25W, 180ohm, 200V, 1% +/-Tol, 100ppm/Cel, Surface Mount, 0805
Technical Details
| Case/Package | 0805 |
| Case Code (Imperial) | 0805 |
| Case Code (Metric) | 2012 |
| China RoHS | Compliant |
| Composition | Thin Film |
| Features | Anti-Sulfur, Moisture Resistant |
| Height | 500µm |
| Lead Free | Lead Free |
| Length | 2mm |
| Lifecycle Status | Production |
| Max Operating Temperature | 155°C |
| Max Power Dissipation | 250mW |
| Min Operating Temperature | -55°C |
| Mount | Surface Mount |
| Number of Terminals | 2 |
| Number of Terminations | 2 |
| Packaging | Cut Tape (CT) |
| Power Dissipation | 250mW |
| Power Rating | 250mW |
| REACH SVHC | Yes |
| Resistance | 180Ω |
| RoHS | Compliant |
| Schedule B | 8533210045, 8533210045|8533210045|8533210045|8533210045|8533210045 |
| Temperature Coefficient | 100ppm/°C |
| Tolerance | 1% |
| Voltage Rating | 200V |
| Width | 1.25mm |
| Working Voltage | 200V |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
