Technical Details
| Color | Red |
| Forward Current | 30mA |
| Forward Voltage | 2.4V |
| Height | 700µm |
| Harmonized Tariff Schedule (HTS) Code | 8541.40.20.00 |
| Introduction Date | 1999-06-01 |
| Luminous Intensity | 25mcd |
| Max Operating Temperature | 85°C |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Circuits | 1 |
| Number of Terminals | 2 |
| Peak Wavelength | 635nm |
| REACH SVHC | Yes |
| Reverse Voltage | 5V |
| RoHS | Compliant |
| Shape | Rectangular |
| Terminal Pitch | 1.6mm |
| Viewing Angle | 150° |
Compliance
RoHS : Unconfirmed
REACH SVHC : Yes
