ESDA6V1W5 - STMicroelectronics
STMicroelectronics ESDA6V1W5 TVS Diode Tape on Reel Surge Protection Device
Technical Details
| Breakdown Voltage | 6.65V |
| Capacitance | 90pF |
| Case/Package | SOT-323-5 |
| China RoHS | Compliant |
| Composition | Zener |
| Country of Origin | Mainland China |
| Depth | 1.35mm |
| Direction | Unidirectional |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Element Configuration | Common Anode |
| ESD Protection | Yes |
| Forward Voltage | 1.25V |
| Height | 1.1mm |
| Harmonized Tariff Schedule (HTS) Code | 8541.10.00.50 |
| Introduction Date | 1980-01-04 |
| Lead Free | Lead Free |
| Leakage Current | 1µA |
| Length | 2.2mm |
| Lifecycle Status | Production |
| Max Breakdown Voltage | 7.2V |
| Max Junction Temperature (Tj) | 125°C |
| Max Operating Temperature | 125°C |
| Max Reverse Leakage Current | 1µA |
| Min Breakdown Voltage | 6.1V |
| Min Operating Temperature | -40°C |
| Mount | Surface Mount |
| Number of Channels | 2 |
| Number of Elements | 4 |
| Number of Pins | 5 |
| Number of Terminals | 5 |
| Number of Unidirectional Channels | 4 |
| Peak Pulse Current | 15A |
| Peak Pulse Power | 150W |
| Peak Reverse Current | 1µA |
| Polarity | Unidirectional |
| Power Line Protection | No |
| Power Rating | 150W |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| Reverse Breakdown Voltage | 6.1V |
| Reverse Standoff Voltage | 3V |
| RoHS | Compliant |
| Schedule B | 8536300000, 8536300000|8536300000, 8536300000|8536300000|8536300000, 8536300000|8536300000|8536300000|8536300000 |
| Termination | SMD/SMT |
| Test Current | 1mA |
| Voltage Rating (DC) | 6.1V |
| Width | 1.35mm |
| Working Voltage | 3V |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
