M24C02-WDW6TP - STMicroelectronics
M24C02 Series 2 Kb (256 x 8) 2.5 V SMT Serial I²C Bus EEPROM - TSSOP-8
Technical Details
| Access Time | 900ns |
| Ambient Temperature Range High | 85°C |
| Case/Package | TSSOP |
| China RoHS | Compliant |
| Contact Plating | Gold, Tin |
| Country of Origin | Morocco |
| Density | 2kb |
| Export Control Classification Number (ECCN) Code | EAR99 |
| Frequency | 400kHz |
| Height | 1.2mm |
| Height - Seated (Max) | 1.2mm |
| Harmonized Tariff Schedule (HTS) Code | 8542.32.00.51 |
| Interface | Serial |
| Introduction Date | 1980-01-04 |
| Lead Free | Lead Free |
| Length | 4.4mm |
| Lifecycle Status | NRND |
| Max Frequency | 400kHz |
| Max Operating Temperature | 85°C |
| Max Supply Current | 2mA |
| Max Supply Voltage | 5.5V |
| Memory Size | 256B |
| Memory Type | EEPROM |
| Manufacturer Package Identifier | TSSOP8-AM |
| Min Operating Temperature | -40°C |
| Min Supply Voltage | 2.5V |
| Mount | Surface Mount |
| Nominal Supply Current | 1mA |
| Number of Circuits | 1 |
| Number of Pins | 8 |
| Number of Terminals | 8 |
| Operating Supply Voltage | 5V |
| Packaging | Tape and Reel |
| Radiation Hardening | No |
| REACH SVHC | Yes |
| RoHS | Compliant |
| Schedule B | 8542320050, 8542320050|8542320050|8542320050|8542320050|8542320050 |
| Temperature Grade | Industrial |
| Terminal Pitch | 650µm |
| Width | 3mm |
Compliance
RoHS : Unconfirmed
Radiation Hardening : No
REACH SVHC : Yes
Images
Future Electronics
Alternatives (Possible Substitutes)
| Manufacturer | Manufacturer Part No. | Lifecycle Status Indicator | Confidence |
|---|---|---|---|
| STMicroelectronics | Obsolete | ||
| STMicroelectronics | Obsolete | ||
| STMicroelectronics | Obsolete | ||
| STMicroelectronics | Production | ||
| STMicroelectronics | Obsolete | ||
| STMicroelectronics | Production | ||
| Microchip | Production | ||
| Microchip | Production | ||
| Microchip | Unknown | ||
| Microchip | Unknown |
